6  POLYMORPHISM

6.1 Basics of Polymorphism

Object Reference and Object Pointer

Object Pointer and Assignment

Polymorphism

General

“Poly” is Greek for many, and “morph” means form. Polymorphism is that feature of object-oriented languages that allows objects of different types to be treated similarly.

C++

Polymorphism allows an object reference variable or an object pointer to reference objects of different types and to call the correct member functions, depending upon the type of object being referenced.

Need for Polymorphic Behavior

  • It is possible that both Tuna and Carp provide their own Tuna::Swim() and Carp::Swim() methods to make Tuna and Carp different swimmers.

  • If a user with an instance of Tuna uses the base class type to invoke Fish::Swim(), he ends up executing only the generic part Fish::Swim() and not Tuna::Swim(), even though that base class instance Fish is a part of a Tuna.

Example 1

classDiagram
   class Fish {
      +void Swim()
   }
   class Tuna {
      +void Swim()
   }
   Fish <|-- Tuna


#include <iostream>
using namespace std;
class Fish {
public:
   void Swim() {
      cout << "Fish swims!" << endl;
   }
};
class Tuna:public Fish {
public:
   // override Fish::Swim
   void Swim() {
      cout << "Tuna swims!" << endl;
   }
};
void MakeFishSwim(Fish& InputFish) {
   // calling Fish::Swim
   InputFish.Swim();
}
int main() {
   Tuna myDinner;
   // calling Tuna::Swim
   myDinner.Swim();
   // sending Tuna as Fish
   MakeFishSwim(myDinner);
   return 0;
}

Polymorphic Behavior Implemented Using Virtual Functions

The virtual function provides the ability to define a function in a base class and have a function of the same name and type in a derived class called when a user calls the base class function.

Syntax

class ⟨Base Class⟩ {
   virtual ⟨return type⟩ ⟨function name⟩ (⟨parameter list⟩);
};

class ⟨Derived Class⟩ : public ⟨Base Class⟩ {
   ⟨return type⟩ ⟨function name⟩ (⟨parameter list⟩);
};

UML

classDiagram
   class ClassName {
      attribute1
      attribute2
      operation1()
      operation2()*
   }
   note for ClassName "italic style means virtual"


classDiagram
   class ClassName {
      attribute1
      attribute2
      operation1()
      virtual operation2()
   }

Example 2

classDiagram
   class Fish {
      +virtual void Swim()
   }
   class Tuna {
      +void Swim()
   }
   class Carp {
      +void Swim()
   }
   Fish <|-- Tuna
   Fish <|-- Carp


#include <iostream>
using namespace std;
class Fish {
public:
   virtual void Swim() {
      cout << "Fish swims!" << endl;
   }
};
class Tuna:public Fish {
public:
   // override Fish::Swim
   void Swim() {
      cout << "Tuna swims!" << endl;
   }
};
class Carp:public Fish {
public:
   // override Fish::Swim
   void Swim() {
      cout << "Carp swims!" << endl;
   }
};
void MakeFishSwim(Fish& InputFish) {
   // calling virtual method Swim()
   InputFish.Swim();
}
int main() {
   Tuna myDinner;
   Carp myLunch;
   // sending Tuna as Fish
   MakeFishSwim(myDinner);
   // sending Carp as Fish
   MakeFishSwim(myLunch);
   return 0;
}

Need for Virtual Destructors

  • What happens when a function calls operator delete using a pointer of type Base* that actually points to an instance of type Derived?

classDiagram
   class Fish {
      +Fish()
      +~Fish()
   }
   class Tuna {
      +Tuna()
      +~Tuna()
   }
   Fish <|-- Tuna


#include <iostream>
using namespace std;
class Fish {
public:
   Fish() {
      cout << "Constructed Fish" << endl;
   }
   ~Fish() {
      cout << "Destroyed Fish" << endl;
   }
};
class Tuna:public Fish {
public:
   Tuna() {
      cout << "Constructed Tuna" << endl;
   }
   ~Tuna() {
      cout << "Destroyed Tuna" << endl;
   }
};
void DeleteFishMemory(Fish* pFish) {
   delete pFish;
}
int main() {
   cout << "Allocating a Tuna on the free store:" << endl;
   Tuna* pTuna = new Tuna;
   cout << "Deleting the Tuna: " << endl;
   DeleteFishMemory(pTuna);
   cout << "Instantiating a Tuna on the stack:" << endl;
   Tuna myDinner;
   cout << "Automatic destruction as it goes out of scope: " << endl;
   return 0;
}
  • To avoid this problem, we use virtual destructors

classDiagram
   class Fish {
      +Fish()
      +virtual ~Fish()
   }


class Fish {
public:
   Fish() {
      cout << "Constructed Fish" << endl;
   }
   virtual ~Fish() { // virtual destructor!
      cout << "Destroyed Fish" << endl;
   }
};

Static binding vs Dynamic binding

Binding

  • The determination of which method in the class hierarchy is to be used for a particular object.

Static (Early) Binding

  • When the compiler can determine which method in the class hierarchy to use for a particular object.

Dynamic (Late) Binding

  • When the determination of which method in the class hierarchy to use for a particular object occurs during program execution.

How Do virtual Functions Work

  • Consider a class Base that declared N virtual functions:
class Base {
public:
   virtual void Func1() {
      // Func1 implementation
   }
   virtual void Func2() {
      // Func2 implementation
   }
   // .. so on and so forth
   virtual void FuncN() {
      // FuncN implementation
   }
};
  • class Derived that inherits from Base overrides Base::Func2(), exposing the other virtual functions directly from class Base:
class Derived: public Base {
public:
   virtual void Func1() {
      // Func1 overrides Base::Func1()
   }
   // no implementation for Func2()
   // ...
   virtual void FuncN() {
      // FuncN overrides Base::FuncN()
   }
};

The compiler sees an inheritance hierarchy and understands that the Base defines certain virtual functions that have been overridden in Derived. What the compiler now does is to create a table called the Virtual Function Table (VFT) for every class that implements a virtual function or derived class that overrides it.

  • Each table is comprised of function pointers, each pointing to the available implementation of a virtual function
void DoSomething(Base& objBase) {
   objBase.Func1();     // invoke Derived::Func1
}
int main()
{
   Derived objDerived;
   objDerived.Func2();  // invoke Base::Func2
   DoSomething(objDerived);
};

Abstract Base Classes and Pure Virtual Functions

  • A pure virtual function is a virtual member function of a base class that must be overridden.
  • When a class contains a pure virtual function as a member, that class becomes an abstract base class.
  • An abstract base class cannot be instantiated.

Syntax

class ⟨Abstract Class⟩ {

public:
   virtual ⟨return type⟩ ⟨function name⟩ (⟨parameter list⟩) = 0;

};

Object-Oriented Design

  • Sometimes it is helpful to begin a class hierarchy with an abstract base class. The abstract base class represents the generic, or abstract, form of all the classes that are derived from it.

Principle

“High-level modules should not depend upon low-level modules. Both should depend upon abstractions.”

“Abstractions should not depend on details. Details should depend on abstractions.”

To know a thing well, we must know its details. To make a thing well, we must know its abstraction.

UML

classDiagram
   class Name {
      <<abstract>>
      operation1()
      operation2()
   }

Example 3

classDiagram
   class Fish {
      <<abstract>>
      +virtual void Swim()
   }
   class Tuna {
      +Swim()
   }
   class Carp {
      +Swim()
   }
   Fish <|-- Tuna
   Fish <|-- Carp


#include <iostream>
using namespace std;
class Fish {
public:
   // a pure virtual function Swim
   virtual void Swim() = 0;
};
class Tuna:public Fish {
public:
   void Swim() {
      cout << "Tuna swims" << endl;
   }
};
class Carp:public Fish {
   void Swim() {
      cout << "Carp swims" << endl;
   }
};
void MakeFishSwim(Fish& inputFish) {
   inputFish.Swim();
}
int main() {
   // Fish myFish;   // Fails
   Carp myLunch;
   Tuna myDinner;
   MakeFishSwim(myLunch);
   MakeFishSwim(myDinner);
   return 0;
}

6.2 Diamond Problem

Replicated based class

  • With the ability of specifying more than one base class, there may be a chance of having the same base class more than once.

Diamond problem

classDiagram
   ClassA <|-- ClassB
   ClassA <|-- ClassC
   ClassB <|-- ClassD
   ClassC <|-- ClassD

  • What happens when we instantiate a Platypus? How many instances of class Animal are instantiated for one instance of Platypus?

Example 4

classDiagram
   class Animal {
      +int Age
      +Animal()
   }
   class Mammal {
   }
   class Bird {
   }
   class Reptile {
   }
   class Platypus {
      +Platypus()
   }
   Animal <|-- Mammal
   Animal <|-- Bird
   Animal <|-- Reptile
   Mammal <|-- Platypus
   Bird <|-- Platypus
   Reptile <|-- Platypus


#include <iostream>
using namespace std;
class Animal {
public:
   Animal() {
      cout << "Animal constructor" << endl;
   }
   int Age;
};
class Mammal:public Animal {
};
class Bird:public Animal {
};
class Reptile:public Animal {
};
class Platypus:public Mammal, public Bird, public Reptile {
public:
   Platypus() {
      cout << "Platypus constructor" << endl;
   }
};
int main() {
   Platypus duckBilledP;
   // Age is ambiguous as there are
   // three instances of base Animal
   duckBilledP.Age = 25;
   return 0;
}

Using virtual Inheritance to Solve the Diamond Problem

  • The solution is in virtual inheritance

Syntax

class ⟨Base Class⟩ {
   ...
};

class ⟨Derived1 Class⟩ : public virtual ⟨Base Class⟩ {
   ...
};

class ⟨Derived2 Class⟩ : public virtual ⟨Base Class⟩ {
   ...
};

class ⟨Derived Class⟩ : public ⟨Derived1 Class⟩, public ⟨Derived2 Class⟩ {
   ...
};

Example 5

classDiagram
   class Animal {
      +int Age
      +Animal()
   }
   class Mammal {
   }
   class Bird {
   }
   class Reptile {
   }
   class Platypus {
      +Platypus()
   }
   Animal <|-- Mammal : virtual
   Animal <|-- Bird : virtual
   Animal <|-- Reptile : virtual
   Mammal <|-- Platypus
   Bird <|-- Platypus
   Reptile <|-- Platypus


#include <iostream>
using namespace std;
class Animal {
public:
   Animal() {
      cout << "Animal constructor" << endl;
   }
   int Age;
};
class Mammal:public virtual Animal {
};
class Bird:public virtual Animal {
};
class Reptile:public virtual Animal {
};
class Platypus:public Mammal, public Bird, public Reptile {
public:
   Platypus() {
      cout << "Platypus constructor" << endl;
   }
};
int main() {
   Platypus duckBilledP;
   // no compile error
   duckBilledP.Age = 25;
   return 0;
}

6.3 Virtual Copy Constructors

Definition

  • It is technically impossible in C++ to have virtual copy constructors

  • Virtual copy constructors are not possible because the virtual keyword in context of base class methods being overridden by implementations available in the derived class are about polymorphic behavior generated at runtime.

  • Constructors, on the other hand, are not polymorphic in nature as they can construct only a fixed type, and hence C++ does not allow usage of the virtual copy constructors.

  • Design pattern: Propotype Pattern

Virtual Clone Method

classDiagram
   class Fish {
      <<abstract>>
      +virtual Fish* Clone()
   }
   class Tuna {
      +Fish* Clone()
   }
   Fish <|-- Tuna


class Fish {
public:
   virtual Fish* Clone() const = 0; // pure virtual function
};

class Tuna:public Fish {
// ... other members
public:
   Fish* Clone() const {      // virtual clone function
      return new Tuna(*this); // return new Tuna that is
                              // a copy of this
   }
};

6.4 Workshop

✒ Quiz

  1. What is a virtual method?

  2. When does static binding take place? When does dynamic binding take place?

  3. What is an abstract base class?

💻 Exercises

  • Programming Challenges of chapter 15 [@Gaddis2014]

9. File Filter

12. Ship , CruiseShip , and CargoShip Classes
